UVP GelStudio™ / UVP GelStudio™ touch

code :

Main Features

  • Available as a stand-alone, touch-screen automated imager or as an external computer operated system for those laboratories with particular IT/Computer requirements.
  • UVP GelStudio/UVP GelStudio touch are available with a 5.0 megapixel 315 camera with a large range of different applications.
  • Optimized for maximum light sensitivity and quick capture speeds in low-light or long exposure applications.
  • Imager features a new Thin-Line Transilluminator with a 21 x 17cm that fits within a convenient pull-out tray
  • Additional user friendly features include: automated emission filter wheel, and for the UVP GelStudio touch, an integrated 13.3 inch touch screen computer.
  • Accessory light options can be expanded to include a UVP Visi-White™ LED Plate or a UVP Visi-Blue™ LED Transilluminator, fiber optic transilluminator and UVP eLITE MultiSpectral Light Source
  • Other accessories include a blot tray for imaging blots closer to the lens, and a USB port for flash drive data export
  • Customer support available, contact us for any questions.

Product Info

UVP GelStudio imagers provide an enhanced imaging experience, with a 13.3” integrated touch screen computer, Thin-Line Transilluminator that fits easily inside the darkroom.

Designed for workflow efficiency and ease-of-use.

The darkroom features a Thin-Line Transilluminator in a slide-out tray for easy access, with uniform and high-intensity UV lighting in a compact form. An imaging area of 21 x 17cm, allows for easy gel imaging and comes with Ethidium bromide filter as well as UV protection shield. The Thin-Line Transilluminator is designed with long-life UV lamps, for minimum service requirements, independent from the number of times the transilluminator is turned on/off. Thin UV lamp technology is instant-on with no need for warm-up to provide high intensity and uniform lighting. A UV intensity switch “low/high” is included for optimal radiation for documentation or for preparative work.

VisionWorks® software is included with all imagers to automate all control settings. The UVP GelStudio touch contains the VisionWorks® touch version of the software, which allows for one-touch Actions to facilitate routine laboratory work. Software facilitates efficient workflows to save precious time that can be used on other laboratory work. Settings allow control of emission filter wheel, focus, zoom, lighting, compositing and other enhancement capabilities. The touch version can also be used with a mouse and keyboard to allow for additional flexibility, plus contains 4GB of memory DDR4, upgradable to 16GB. Data can be exported in different file formats to a flash drive or another file source for storage.

Software capabilities within the VisionWorks® Acquisition and Analysis Software includes: 1D quantitation, area density, colony counting analysis. Data reports shows Molecular Weight, Rf, band intensities, and other capabilities which can be exported to external storage files. Software is available in unlimited copies and features support for 21 CFR Part 11.

Darkroom contains five-position filter wheel in a slide-out tray on the right side of the system. Illumination includes overhead red, green, blue & white LED and is all software automated. Additional lighting modules include IR options, 80mW and 150mW. System has 5.0 megapixel camera, with 8 to 48 mm f/1.2 automatic zoom lenses.

Safety protection.

Systems are equipped with a red UV On indicator light, to alert users of the presence of UV light.

Customer service and technical support is available upon request. Analytik Jena has specialized support teams always available. Bioimaging specialists can also provide on-site demos for installation, technical information, and upgrades.

IQ/OQ documents are available as well as on-site service can be provided upon request.

Specifications and Features

Camera Resolution 2592 x 1944 pixels (5.0 MP)
Lens 8-48 mm, f/1.2, automated zoom lens
Data Depth 12 bit
File Depth 16 bit
Filter Wheel Five-position automated filter wheel
Light Sources
  • Overhead red, green, blue & white light included.
  • Overhead IR1, Laser Diode 80mW, 650nm
  • Overhead IR2, Laser Diode 150mW, 780nm
  • Thin-line transilluminator (16.8 x 21 cm filter size). Includes 302 nm UV with LOW and HIGH intensity control
  • UVP Visi-Blue™ Transilluminator with 460nm
  • UVP Visi-White™ Transilluminator
Darkroom Features
  • Weight: 75 lbs
  • Dimensions: 18 x 24 x15in (46 x 61 x 38cm)
  • 13.3” integrated, multi-touch computer (UVP GelStudio touch only)
  • Thin-Line Transilluminator in a pull-out tray
  • Integrated, slide-down, UV Protection shield
  • UV On indicator light
  • 7 USB 2.0 ports
  • Access port for optional UVP eLITE MultiSpectral Light Source
Accessories Included
  • Ethidium bromide filter
  • VisionWorks® Acquisition and Analysis Software for image capture and enhancement (multiple copies available)
  • UVP Fluorescent Focus Target
  • UVP Gel Tray
  • Keyboard and mouse (UVP GelStudio touch only)
